120 V TO 12 V BATTERY CHARGERS – IBC SERIES

FOR SLEEPER TRUCKS & LARGE UTILITY TRUCKS


The IBC Series is designed to reduce your operating costs & garantee engine start of your vehicles. Whether it’s providing additional recharging capacity when the vehicle is stopped, recharging an auxiliary battery bank, or keeping a vehicle’s batteries fully charged in cold weather, our multi-mode battery chargers stand out with their performance and exceptional durability.


KEY BENEFITS & FEATURES
– Fully automatic
– Safe for batteries
– Sturdy design
– Ultra-reliable
– 4 charging modes
– For permanent installation

INSTRUCTION MANUALS & DETAILED SPECIFICATIONS

SPECIFICATIONS

Model IBC45 IBC70 IBC80
Part Number TUN412001 TUN412002 TUN412003
Continuous Charging Power 45A 70A 80A
AC Input Voltage 120 VAC 120 VAC 120 VAC
Nominal Output Voltage 12 VDC  12 VDC  12 VDC
AC Input Cord NEMA 5/15 P  NEMA 5/15 P  NEMA 5/20 P*
(* 120 VAC/20 A input required)
Charging Modes 4 modes
(normal, boost, float & equalize)
4 modes
(normal, boost, float & equalize)
4 modes
(normal, boost, float & equalize)
AC Input Consumption 8.3 A 13.1 A 14.9 A
Dimensions 8.3 x 7.3 x 4.5 po 8.0 x 9.0 x 3.6 po 8.0 x 9.0 x 3.6 po
Weight 4.5 lb / 2.0 kg 5.7 lb / 2.6 kg 5.9 lb / 2.7 kg
Price (MSRP) $293 $388 $584
Icone ÉTOILE

99.1% RATE
OVER 2 YEARS

Icon de tirelire

UNRIVALLED
SAFETY

Icone de tirelire

LOWEST COST OF
OWNERSHIP

Icone ENCLUME

HIGH OUTPUT
CAPACITY

Icon de crochet sur bouclier

ULTRA HIGH
EFFICIENCY
